Specifications

• Weight:
• Frame Weight: 5 kg
• Recommended Battery (14S 40000 mAh): 9.8 kg
• Empty Weight (No Payload, No Battery): 12.5 kg
• Recommended Payload: 12 kg
• Recommended Take-off Weight: 35 kg
• Maximum Take-off Weight (Including Battery): 40 kg
• Frame:
• Wheelbase: 1375 mm
• Opened Size: 1070x1070x600 mm
• Folded Size: 630x630x600 mm
• Frame Weight: 5 kg
• Propellers:
• Diameter × Pitch: 36×19 inch (Foldable)
• Battery:
• Battery Type: Li-ion or LiPo
• Voltage: 14S (56V)
• Capacity: 40 Ah
• Max Discharge Current: 450A
• Total Battery Weight: 10 kg (2 batteries, 20A each)
• Speed:
• Cruising Speed (With Payload): 60 km/h
• Cruising Speed (No Payload): 75 km/h
• Max Flight Speed (With Payload): 70 km/h
• Max Flight Speed (No Payload): 90 km/h
• Range:
• Distance: 20+ km
• Data Transmission Distance: 20+ km
• Control Link: 20+ km
• Video Transmission Distance: 20+ km
• Suggested Flight Altitude: 500m
• Max Flight Altitude: 2000m
• Flight Time:
• Recommended (Full Payload): 20 minutes
• Max Flight Time (Full Payload): 22 minutes
• Max Flight Time (No Payload): 50 minutes
• Working Temperature: -20°C to +50°C
• Max Wind Resistance: Level 7

Gimbal

• Axis: 3
• Zoom: 30X Hybrid, 10X Optical Zoom
• Quality: 2K 4MP QHD

Payload

• 3 Mortar 80mm
• Release Mechanism: 3
